24awg 75c 300v Tinned Copper XLPE Wires UL3194 Stranded Conductor

  • 1
  • 2

Brand Name : Mysun

Model Number : UL3194

Certification : ROHS/CCC/VDE/CCC/ISO9001:2008

Place of Origin : Guangdong，China

MOQ : 3050meters

Price : 0.06~0.48USD per M

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 500000 Meters per Day

Delivery Time : 7-15 working day

Packaging Details : Standard packge: cardboard box Accept custom-made.

Conductor Type : Stranded

Color : Red

Usage : Widely used in home appliance ,lighting ,heater,motor & generator,UAU,robot,industrial power etc

Rated Voltage : 600v

Rated Temperature : 75C

Size : 24AWG

Conductor : Tinned Copper

Standard : UL758

Insulation : XLPE

Type : insulated

Max.Cond Resistance : 94.2 Ω/KM

Construction : 11/0.16

Contact Now

UL3194 24awg 75c 300v tinned copper wires and cables



 UL 3194  Specifications:

Nominal voltage:600V

Temperature range: 75℃

Standard: UL3194

Insulation: xlpe

Conductor: Tinner copper





Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.







Product Parameter



Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.


CONDUCTOR INSULATION MAX.COND RESISTANCE UNIT LENGTH(M)(Ft)
SIZE CONSTRUCTION (NO./mm) DIAMETER (mm) NOMINAL THICKNESS (mm) DIAMETER (Ω/KM)
(AWG) (mm)
27 7/0.14 0.42 0.39 1.2 174 305(1000)
26 7/0.16 0.48 1.26 143
24 11/0.16 0.6 1.38 89.3
22 17/0.16 0.76 1.54 56.4
20 21/0.18 0.94 1.72 35.2
18 16/0.254 1.18 1.96 22.2
16 26/0.254 1.5 2.28 14



Our Product



24awg 75c 300v Tinned Copper XLPE Wires UL3194 Stranded Conductor



Product Description



24awg 75c 300v Tinned Copper XLPE Wires UL3194 Stranded Conductor

Package & Delivery



Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days



24awg 75c 300v Tinned Copper XLPE Wires UL3194 Stranded Conductor
