UL3173 Tinned Copper XLPE Electric Wires 9AWG 125C Insulated

  • 1
  • 2

Brand Name : Mysun

Model Number : UL3173

Certification : ROHS/CCC/VDE/CCC/ISO9001:2008

Place of Origin : Guangdong，China

MOQ : 3050meters

Price : 0.06~0.48USD per M

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 500000 Meters per Day

Delivery Time : 7-15 working day

Packaging Details : Standard packge: cardboard box Accept custom-made.

Conductor Type : Stranded

Color : Black

Usage : Widely used in home appliance ,lighting ,heater,motor & generator,UAU,robot,industrial power etc

Rated Voltage : 600v

Rated Temperature : 125C

Size : 9AWG

Conductor : Tinned Copper

Standard : UL758

Insulation : XLPE

Type : insulated

Max.Cond Resistance : 2.82 Ω/KM

Construction : 133/0.254

Contact Now

XLPE electric wires UL3173 9AWG 125 C for new energy automobile



 UL 3173  Specifications:

Nominal voltage:600V

Temperature range: 125℃

Standard: UL3173

Insulation: xlpe

Conductor: Tinner copper





Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.







Product Parameter



Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.


Conductor Insulation Max.Cond Resistance Unit length
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		 Nominal Thickness
(mm)		 Diameter
(mm)		 (Ω/KM) (M)(Ft)
26 7/0.16 0.48 0.78 2.04 143 305/1000
24 11/0.16 0.60 2.16 89.3
22 17/0.16 0.76 2.32 56.4
20 21/0.18 0.94 2.49 35.2
18 16/0.254 1.18 2.73 22.2
16 26/0.254 1.50 3.06 14
14 41/0.254 1.89 3.45 8.78
12 65/0.254 2.37 3.93 5.53
10 105/0.254 3.02 4.58 3.476
9 133/0.254 3.36 4.92 2.73



Our Product



UL3173 Tinned Copper XLPE Electric Wires 9AWG 125C Insulated



Product Description



UL3173 Tinned Copper XLPE Electric Wires 9AWG 125C Insulated

Package & Delivery



Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days



UL3173 Tinned Copper XLPE Electric Wires 9AWG 125C Insulated







Company Introduction



UL3173 Tinned Copper XLPE Electric Wires 9AWG 125C Insulated

UL3173 Tinned Copper XLPE Electric Wires 9AWG 125C Insulated
